The TA-A57 Low PIM Termination is a high-performance RF termination engineered for Distributed Antenna Systems (DAS), wireless infrastructure, and commercial communication networks. Operating from 350 MHz to 6000 MHz, it delivers outstanding low PIM performance, excellent return loss, and reliable power handling for demanding RF environments. Designed for efficient signal termination and long-term network reliability, the TA-A57 is ideal for DAS installations, cellular networks, in-building wireless systems, and broadband RF distribution.
General Specifications:
Device Type: Low PIM Termination
Model Number: TA-A57
Frequency Range: 350 – 6000 MHz
Power Handling: 40 W Average (CW) Max
PIM Performance: -160 dBc Maximum (2 × 20 W @ 1900 MHz)
Return Loss: 15.5 dB to 22 dB (Frequency Dependent)
DC Return: Open
Connector Options: 4.3-10, 7-16 DIN, Type N, NEX10 (Male or Female)
Configuration: Disk Load with Tail
Application Areas: Distributed Antenna Systems (DAS), wireless infrastructure, cellular networks, in-building wireless systems, broadband RF distribution, RF testing, and commercial communication networks.
