QRH600 is a dual-polarized quad ridged horn antenna covering 600 MHz to 9 GHz. It is well suited for EMC testing, wireless development, and wideband measurement applications where dual linear polarization and repeatable setup are important.
Electrical Specifications
Frequency Range: 600 MHz to 9 GHz
VSWR (max.): 2
VSWR (avg.): 1.4
Impedance: 50 Ohm
Connector: N (female)
Power (CW / Peak): 125 W / 200 W
Antenna Factor: 20 to 35 dB/m
Port Isolation: -32 dB
Polarization: Dual Linear, Circular with hybrid
Physical Specifications
Width: 247 mm (9.724 in)
Height: 247 mm (9.724 in)
Depth: 292 mm (11.496 in)
Weight: 1.63 kg (3.594 lb)
Operating Conditions
Rated Temperature Range: 0°C – +50°C
Storage Temperature Range: -20°C – +70°C
Contact sales@impulse-tech.com for full datasheet
