NXM-60 Network Spectrum Analyzer
General Specifications:
Frequency range: 9 kHz – 6.3 GHz
Analysis Bandwidth: 100 MHz
DANL (1 GHz): –161 dBm/Hz
Phase noise (1 GHz, 10 kHz offset): –114 dBc/Hz (typical)
Sweep speed: 175 GHz/s
Dynamic Range: –160 dBm/Hz
Interface: 1000M/100M Ethernet
Processor Support: ARM and x86 architectures
Operating Systems: Windows and Linux
API Compatibility: Harogic SDK and Network API Integration
Analysis Bandwidth: 100 MHz
DANL (1 GHz): –161 dBm/Hz
Phase noise (1 GHz, 10 kHz offset): –114 dBc/Hz (typical)
Sweep speed: 175 GHz/s
Dynamic Range: –160 dBm/Hz
Interface: 1000M/100M Ethernet
Processor Support: ARM and x86 architectures
Operating Systems: Windows and Linux
API Compatibility: Harogic SDK and Network API Integration
Note: All data are typical values. All data are simulated. Actual values could vary slightly.
