K/Ka-Band SAT System

In Stock

K/Ka-Band DCP Antenna (2211-218 K/Ka band)

• K/Ka Band
• Four-port configuration
• <1 dB of Axial Ratio
• Compact size (2U)
Parameter Typical Value
Frequency band – Pass band TX 17.3–21.2 GHz
Frequency band – Pass band RX 27–31 GHz
Return Loss 18 dB
Isolation TX/RX & RX/TX 80–100 dB
Directivity 21 dBi
Axial Ratio 0.8 dB
Cross-Polar Level 20 dB
Angular Beamwidth 10º
Polarization RHCP & LHCP for both TX and RX
Connectors Coaxial 2.92 mm (F)
Size 102 x 102 x 197 mm (2U)
Mass 620 g
TRL 8* (Flight program, 2024)

Click to view datasheet

Request a Quote
Categories: ,
ENGINEERING DATA / K/KA-BAND

SPECIFICATION WORKSPACE

Technical data, resources and engineering actions for this exact catalog model.

ANTERALIN STOCKLimited DATA COVERAGE
01
KEY SPECIFICATIONSCatalog values for K/Ka-Band
Frequency17.3–21.2 GHz
ENGINEERING USE: Confirm mechanical interface, environmental requirements, qualification level and application-specific limits before final design release. Published catalog values remain controlling where differences exist.
03 / NEXT ACTIONMOVE FROM PART DATA TO AN ENGINEERING DECISION.
COMPARECompare This ProductOpen the 4-product SpecMatch comparison → ALTERNATIVESFind Equivalent PartsUse CrossMatch against this model → MODIFY / BUILDCustom RequirementSend an engineering requirement →
PROCUREMENTAdd to RFQ
ADD TO RFQ

Description

Anteral’s K/Ka-Band SAT System is a compact, four-port solution designed for smallsats and advanced satellite platforms. It operates in both transmit (17.3–21.2 GHz) and receive (27–31 GHz) bands, offering dual-circular polarization with less than 1 dB of axial ratio—thanks to an advanced polarizer design developed in-house.

With 80–100 dB of isolation between TX and RX channels, this system ensures clear, interference-free performance for demanding RF environments. The antenna delivers 21 dBi of directivity in a lightweight 2U form factor, making it ideal for NewSpace applications where mass and volume are limited.

Multiple clamping points allow for mechanical customization. The system is currently qualified for a 2024 flight program and supports both RHCP and LHCP on TX and RX ports.

NEED HELP WITH THIS RF COMPONENT?Ask Impulse Sales

Get help with specifications or sourcing

Tell us what you need for K/Ka-Band SAT System. Impulse Sales can follow up about specifications, matching products, or a quotation.

This is a one-to-one product-assistance request, not newsletter signup. Don't submit controlled or export-restricted technical details. See our privacy policy.
