The IZ337 TEMPEST Turntable is a precision-engineered turntable designed for TEMPEST measurements in anechoic chambers according to SDIP-27/2 standards. Featuring automated fiber optic control, a wide ±180° rotation range, and SCPI command compatibility, the IZ337 is ideal for secure electromagnetic testing, antenna positioning, and automated EMC/TEMPEST laboratory applications.

General Specifications:

Device Type: TEMPEST Turntable
Model Number: IZ337
Application Standard: SDIP-27/2
Rotation Range: ±180°
Control Interface: Fibre Optic Interface
Automation Support: SCPI Commands Compatible
Network Interface: Two Fiber Optic Ports, SFP Compatible, 1 Gbit/s
Position Sensor: Integrated
Power Supply: DC Power Supply
Rotating Plate Diameter: 0.9 m
Dimensions: 2 × 1 × 0.85 m
Application Areas: TEMPEST measurements, EMC testing, automated antenna positioning, anechoic chamber testing, electromagnetic security measurements
Design Features: Low electromagnetic radiation optimized construction for secure measurement environments
