ITi3-6

In Stock

Free shipping!

Quantities of 9+, please request a quote for bulk pricing.

Specifications:

Frequency: 3.0-6.0GHz
Isolation: 21dB Typ., 19dB Min.
Insertion Loss: 0.35dB Typ., 0.4dB Max.
VSWR: 1.25 Typ., 1.30 Max.
Power: 2W Avg., 20W Peak
Connectors: SMA-F

Click to view datasheet

ENGINEERING DATA / ITI3-6

SPECIFICATION WORKSPACE

Technical data, resources and engineering actions for this exact catalog model.

IMPULSE IN-HOUSEIN STOCKHigh DATA COVERAGE
01
KEY SPECIFICATIONSCatalog values for ITi3-6
Frequency3–6 GHz
Phase Adjust30°
ConnectorSMA-F
VSWR Max1.3:1
Average Power2 W
Peak Power20 W
Insertion Loss0.35dB Typ., 0.4dB Max.
ENGINEERING USE: Confirm mechanical interface, environmental requirements, qualification level and application-specific limits before final design release. Published catalog values remain controlling where differences exist.

Description

Isolator model ITi3-6 is an octave-band model with a frequency range of 3.0-6.0GHz. Equipped with SMA-F connectors, and operable at temperatures between -30°C to +85°C, Isolator ITi3-6 has a rated isolation of 21dB Typ. (19dB Min.), rated loss of 0.35dB Typ. (0.4dB Max.) and VSWR of 1.25 Typ. (1.30 Max.). Isolator ITi3-6 is in-stock and can be shipped domestically and internationally upon order placement.
