The AM000314LN-P1 is a broadband low noise amplifier (LNA) module designed for RF systems requiring low noise figure and stable gain across a wide frequency range. Operating from 10 MHz to 250 MHz, this amplifier provides excellent noise performance with a typical noise figure of 1.4 dB and consistent gain of approximately 17 dB. The module is internally matched to 50 ohms and features SMA connectors for both input and output, enabling easy integration into test equipment, communication systems, and signal chain applications.
General Specifications:
Device Type: Low Noise Amplifier (LNA Module)
Frequency Range: 10 MHz – 250 MHz
Small Signal Gain: 16–17.5 dB (typical ~17 dB)
Noise Figure: 1.4 dB (typical)
P1dB Output Power: 21 dBm (typical)
Third Order Intercept (IP3): 39 dBm (typical)
Input Power: 20 dBm (maximum)
Input Return Loss (VSWR): 1.4:1 (typical)
Output Return Loss (VSWR): 1.1:1 (typical)
Reverse Isolation: -20 dB (typical)
Input / Output Impedance: 50 Ohms (matched)
Bias Conditions: Vcc = +5 V, Idc ≈ 160 mA
Package: Connectorized Module with SMA interfaces
